SFI立昌SFI0402-120E100NP-LF

SFI立昌ESD SFI0402-120E100NP-LF 0402 12V 10PF

含税价格：

￥111 /个

商品规格：

购买数量：

个库存100000个，10000个起售

规格说明：

SFI立昌SFI0402-120E100NP-LF

交付说明：

硬件交付实时交付

运费说明：

卖家承担运费

开票信息：

支持开具增值税专用发票(可抵扣)

服务保障：

质保期1年

同意

《AI市场服务协议》《商品服务协议》

立即购买

咨询详情

电话询价

产品详情

产品亮点

SFI立昌一级代理分销KOYUELEC光与电子SFI0402-120E100NP-LF

产品说明

0402 12V 10PF的压敏电阻

Part Number Working Voltage Working Voltage Breakdown Voltage Clamping Voltage Surge Current

Symbol VAC VDC VB(1mA) VC(max.) IPeak(8/20μs)

SFI0805ML240A-LF 14V 18V 24V 39V 150A

SFI1206ML180A-LF 11V 14V 18V 30V 200A

SFI1206ML240A-LF 14V 18V 24V 39V 200A

SFI1206ML330A-LF 20V 26V 33V 54V 200A

SFI1206ML390A-LF 25V 30V 39V 65V 200A

SFI1206ML470A-LF 30V 38V 47V 77V 200A

SFI1210ML240A-LF 14V 18V 24V 39V 400A

SFI1210ML270A-LF 17V 22V 27V 44V 400A

SFI1210ML330A-LF 20V 26V 33V 54V 400A

SFI1210ML390A-LF 25V 30V 39V 65V 400A

SFI1210ML470A-LF 30V 38V 47V 77V 400A

SFI1812ML240A-LF 14V 18V 24V 39V 800A

SFI1812ML390A-LF 25V 30V 39V 65V 800A

SFI1812ML470A-LF 30V 38V 47V 77V 800A

SFI1812ML560A-LF 35V 45V 56V 90V 800A

SFI2220ML180A-LF 11V 14V 18V 30V 1200A

SFI2220ML240A-LF 14V 18V 24V 39V 1200A

SFI2220ML270A-LF 17V 22V 27V 44V 1200A

SFI2220ML330A-LF 20V 26V 33V 54V 1200A

SFI2220ML390A-LF 25V 30V 39V 65V 1200A

SFI2220ML470A-LF 30V 38V 47V 77V 1200A

SFI2220ML560A-LF 35V 45V 56V 90V 1200A

Part Number Working Voltage Working Voltage Breakdown Voltage Clamping Voltage Surge Current

Symbol VAC VDC VB(1mA) VC(max.) IPeak(8/20μs)

SFI0402ML080C-LF 4V 5.5V 8V 20V 20A

SFI0402ML120C-LF 6V 9V 12V 24V 20A

SFI0402ML180C-LF 11V 14V 18V 35V 20A

SFI0402ML240C-LF 14V 18V 24V 44V 20A

SFI0603ML080C-LF 4V 5.5V 8V 20V 30A

SFI0603ML080CS-LF 4V 5.5V 8V 20V 30A

SFI0603ML120C-LF 6V 9V 12V 24V 30A

SFI0603ML180C-LF 11V 14V 18V 30V 30A

SFI0603ML240C-LF 14V 18V 24V 39V 30A

SFI0603ML270C-LF 17V 22V 27V 44V 30A

SFI0603ML330C-LF 20V 26V 33V 54V 30A

SFI0603ML390C-LF 25V 30V 39V 65V 30A

SFI0603ML470C-LF 30V 38V 47V 77V 30A

SFI0805ML080C-LF 4V 5.5V 8V 20V 80A

SFI0805ML120C-LF 6V 9V 12V 24V 80A

SFI0805ML180C-LF 11V 14V 18V 30V 100A

SFI0805ML240C-LF 14V 18V 24V 39V 100A

SFI0805ML270C-LF 17V 22V 27V 44V 100A

SFI0805ML330C-LF 20V 26V 33V 54V 100A

SFI0805ML390C-LF 25V 30V 39V 65V 100A

SFI0805ML470C-LF 30V 38V 47V 77V 100A

SFI0805ML560C-LF 35V 45V 56V 90V 80A

SFI1206ML080C-LF 4V 5.5V 8V 20V 100A

SFI1206ML101C-LF 60V 85V 100V 165V 100A

SFI1206ML180C-LF 11V 14V 18V 30V 100A

SFI1206ML240C-LF 14V 18V 24V 39V 100A

SFI1206ML270C-LF 17V 22V 27V 44V 100A

SFI1206ML330C-LF 20V 26V 33V 54V 100A

SFI1206ML390C-LF 25V 30V 39V 65V 100A

SFI1206ML470C-LF 30V 38V 47V 77V 100A

SFI1206ML560C-LF 35V 45V 56V 90V 100A

SFI1206ML680C-LF 40V 56V 68V 110V 100A

SFI1206ML820C-LF 50V 65V 82V 135V 100A

SFI1210ML080C-LF 4V 5.5V 8V 20V 250A

SFI1210ML101C-LF 60V 85V 100V 165V 200A

SFI1210ML240C-LF 14V 18V 24V 39V 250A

SFI1210ML330C-LF 20V 26V 33V 54V 250A

SFI1210ML390C-LF 25V 30V 39V 65V 250A

SFI1210ML560C-LF 35V 45V 56V 90V 250A

SFI1210ML680C-LF 40V 56V 68V 110V 250A

SFI1812ML470C-LF 30V 38V 47V 77V 500A

SFI1812ML151C-LF 95V 127V 150V 270V 600A

SFI1812ML560C-LF 35V 45V 56V 90V 500A

SFI2220ML270C-LF 17V 22V 27V 44V 1000A

SFI2220ML330C-LF 20V 26V 33V 54V 1000A

SFI2220ML390C-LF 25V 30V 39V 65V 1000A

SFI2220ML470C-LF 30V 38V 47V 77V 1000A

SFI2220ML680C-LF 40V 56V 68V 110V 1000A

应用场景

各类电子产品端口用于一些过压过流保护电路应用

Part Number Working Voltage Breakdown Voltage Clamping Voltage Typical Capacitance ESD Ability

Symbol VDC VB(1mA) VC(max.) C(1KHz) Contact

SFI0201-050E050PP-LF 5V 28~38V 72V 5.0pF(+80~-20%) 8KV

SFI0201-050E100NP-LF 5V 28~38V 72V 10pF(±30%) 8KV

SFI0201-050E330NP-LF 5V 18~28V 48V 33pF(±30%) 8KV

SFI0201-120E0R8PP-LF 12V 100~150V 200V 0.8pF(+80~-20%) 8KV

SFI0201-120E2R5PP-LF 12V 60~80V 130V 2.5pF(+80~-20%) 8KV

SFI0402-050E050PP-LF 5V 28~38V 72V 5.0pF(+80~-20%) 8KV

SFI0402-050E100NP-LF 5V 28~38V 72V 10pF(±30%) 8KV

SFI0402-050E101NP-LF 5V 18~28V 52V 100pF(±30%) 8KV

SFI0402-050E220NP-LF 5V 18~28V 52V 22pF(±30%) 8KV

SFI0402-050E330NP-LF 5V 18~28V 52V 33pF(±30%) 8KV

SFI0402-050E560NP-LF 5V 18~28V 52V 56pF(±30%) 8KV

SFI0402-120E050PP-LF 12V 28~38V 72V 5.0pF(+80~-20%) 8KV

SFI0402-120E100NP-LF 12V 28~38V 72V 10pF(±30%) 8KV

SFI0402-120E101NP-LF 12V 20~30V 55V 100pF(±30%) 8KV

SFI0402-120E220NP-LF 12V 20~30V 55V 22pF(±30%) 8KV

SFI0402-120E330NP-LF 12V 20~30V 55V 33pF(±30%) 8KV

SFI0402-120E560NP-LF 12V 20~30V 55V 56pF(±30%) 8KV

SFI0402-240E0R8PP-LF 24V 100~150V 200V 0.8pF(+80~-20%) 8KV

SFI0402-240E1R8PP-LF 24V 100~150V 200V 1.8pF(+80~-20%) 8KV

SFI0402-240E2R5PP-LF 24V 100~150V 200V 2.5pF(+80~-20%) 8KV

SFI0402-240E3R0PP-LF 24V 48~72V 110V 3.0pF(+80~-20%) 8KV

SFI0402-420E0R8PP-LF 42V 100~150V 200V 0.8pF(+80~-20%) 8KV

SFI0402-420E2R5PP-LF 42V 100~150V 200V 2.5pF(+80~-20%) 8KV

SFI0603-050E050PP-LF 5V 20~30V 55V 5.0pF(+80~-20%) 8KV

SFI0603-050E100NP-LF 5V 24~36V 65V 10pF(±30%) 8KV

SFI0603-050E101NP-LF 5V 15~25V 36V 100pF(±30%) 8KV

SFI0603-050E220NP-LF 5V 15~25V 34V 22pF(±30%) 8KV

SFI0603-050E330NP-LF 5V 15~25V 34V 33pF(±30%) 8KV

SFI0603-050E560NP-LF 5V 15~25V 36V 56pF(±30%) 8KV

SFI0603-120E050PP-LF 12V 33~50V 85V 5.0pF(+80~-20%) 8KV

SFI0603-120E100NP-LF 12V 27~42V 60V 10pF(±30%) 8KV

SFI0603-120E101NP-LF 12V 20~30V 55V 100pF(±30%) 8KV

SFI0603-120E220NP-LF 12V 20~30V 55V 22pF(±30%) 8KV

SFI0603-120E330NP-LF 12V 20~30V 55V 33pF(±30%) 8KV

SFI0603-240E0R8PP-LF 24V 100~150V 200V 0.8pF(+80~-20%) 8KV

SFI0603-240E2R5PP-LF 24V 100~150V 200V 2.5pF(+80~-20%) 8KV

SFI0603-240E3R0PP-LF 24V 48~72V 110V 3.0pF(+80~-20%) 8KV

SFI0603-5R5T100NP-LF 5V 15~20V 36V 10pF(±30%) 8KV

SFI0805-050E560NP-LF 5V 20~28V 60V 56pF(±30%) 8KV

SFI0805-120E560NP-LF 12V 20~30V 60V 56pF(±30%) 8KV

Part Number Stand-off Voltage Breakdown Voltage Clamping Voltage Typical Capacitance Leakage Current

Symbol VDC(max.) VB(1mA) VC(max.) C(1MHz) ILDC

SFI0402EA240-HSP 16V 28.0~38.0V 57V 15pF <0.8μA

SFI0402EA470-HSP 28V 48.0~72.0V 108V 15pF <0.8μA

Part Number Stand-off Voltage Breakdown Voltage Clamping Voltage Typical Capacitance Leakage Current

Symbol VDC(max.) VB(1mA) VC(max.) C(1MHz) ILDC

SFI0603EA240-HSP 16V 28.0~38.0V 57V 10pF <0.8μA

SFI0603EA240-LSP 16V 28.0~38.0V 57V 50pF <0.8μA

SFI0603EA240-MSP 16V 28.0~38.0V 57V 25pF <0.8μA

SFI0603EA470-HSP 28V 48.0~72.0V 108V 15pF <0.8μA

SFI0603EA470-LSP 28V 48.0~72.0V 108V 50pF <0.8μA

SFI0603EA510-LSP 32V 52.0~76.0V 110V 50pF <0.8μA

SFI0603EA680-HSP 42V 70.0~95.0V 140V 15pF <0.8μA

SFI0603EA111-HSP 70V 110.0~140.0V 200V 15pF <0.8μA

Part Number Stand-off Voltage Breakdown Voltage Clamping Voltage Typical Capacitance Leakage Current

Symbol VDC(max.) VB(1mA) VC(max.) C(1MHz) ILDC

SFI0805EA470-XSP 36V 42.3~51.7V 77V 200pF <2.0μA

Part Number Working Voltage Breakdown Voltage Clamping Voltage(ESD and TLP) Clamping Voltage(ESD and TLP) Jump Start Voltage(5min)

Symbol VDC(max.) VB(1mA) VC(8/20μs) VC(pulse1) V JUMP

SFI0806EV280-L4 16V 27~30V 45V 60V 30V

SFI0806EV450-L4 32V 43~47V 66V 80V 46V

Part Number Working Voltage Breakdown Voltage Peak Current Load Dump

(10 times) Jump Start Voltage(5min)

Symbol VDC(max.) VB(1mA) IPeak(8/20μs) WLD V JUMP

SFI0805SA240-1R5J 16V 24V 200A 1.5J 24.5V

Part Number Working Voltage Breakdown Voltage Peak Current Load Dump

(10 times) Jump Start Voltage(5min)

Symbol VDC(max.) VB(1mA) IPeak(8/20μs) WLD V JUMP

SFI0806SA240-060J 16V 24V 300A 6J 24.5V

SFI0806SA300-090J 16V 30V 300A 9J 30.0V

SFI0806SA330-090J 16V 33V 300A 9J 32.5V

SFI0806SA360-090V 24V 36V 300A 9J 35.0V

Part Number Working Voltage Breakdown Voltage Peak Current Load Dump

(10 times) Jump Start Voltage(5min)

Symbol VDC(max.) VB(1mA) IPeak(8/20μs) WLD V JUMP

SFI1206SA240-030J 16V 24V 400A 3J 24.5V

SFI1206SA240-060J 16V 24V 500A 6J 24.5V

SFI1206SA330-060J 16V 33V 200A 6J 32.5V

SFI1206SA360-090J 16V 36V 500A 9J 35.0V

SFI1206SA360-090V 24V 36V 500A 9J 35.0V

SFI1206SA470-030J 34V 47V 200A 3J 45.0V

Part Number Working Voltage Breakdown Voltage Peak Current Load Dump

(10 times) Jump Start Voltage(5min)

Symbol VDC(max.) VB(1mA) IPeak(8/20μs) WLD V JUMP

SFI1210SA240-060J 16V 24V 800A 6J 24.5V

SFI1210SA240-120J 16V 24V 400A 3J 24.5V

SFI1210SA360-120J 16V 36V 800A 12J 35.0V

SFI1210SA360-120V 24V 36V 800A 12J 35.0V

SFI1210SA470-120J 34V 47V 500A 12J 45.0V

Part Number Working Voltage Breakdown Voltage Peak Current Load Dump

(10 times) Jump Start Voltage(5min)

Symbol VDC(max.) VB(1mA) IPeak(8/20μs) WLD V JUMP

SFI1812SA240-120J 16V 24V 1600A 12J 24.5V

SFI1812SA240-200J 16V 24V 2000A 20J 24.5V

SFI1812SA360-250J 16V 38V 2000A 25J 35.0V

SFI1812SA360-250V 24V 36V 2000A 25J 35.0V

SFI1812SA470-250J 34V 47V 2000A 25J 45.0V

Part Number Working Voltage Breakdown Voltage Peak Current Load Dump

(10 times) Jump Start Voltage(5min)

Symbol VDC(max.) VB(1mA) IPeak(8/20μs) WLD V JUMP

SFI2220SA240-500J 16V 24V 5000A 50J 24.5V

SFI2220SA330-500J 16V 33V 5000A 50J 32.5V

SFI2220SA360-500J 16V 36V 4000A 50J 35.0V

SFI2220SA360-500V 24V 36V 4000A 50J 35.0V

SFI2220SA470-250J 34V 47V 3000A 25J 45.0V

SFI2220SA470-500J 34V 47V 4000A 50J 45.0V

Part Number Working Voltage Breakdown Voltage Peak Current Load Dump

(10 times) Jump Start Voltage(5min)

Symbol VDC(max.) VB(1mA) IPeak(8/20μs) WLD V JUMP

SFI3220SA240-800J 16V 24V 5500A 80J 24.5V

SFI3220SA470-500J 34V 47V 4000A 50J 45.0V

SFI3220SA470-800J 34V 47V 4500A 80J 45.0V

使用方式

消费类电子产品

Part Number Working Voltage Breakdown Voltage Peak Current Load Dump

(10 times) Jump Start Voltage(5min)

Symbol VDC(max.) VB(1mA) IPeak(8/20μs) WLD V JUMP

SFI4032SA240-161J 16V 24V 6000A 160J 24.5V

SFI4032SA360-161V 24V 36V 6000A 160J 35.0V

SFI4032SA470-161J 36V 45.0~53.0V 6000A 160J 48.0V

SFI4032SA770-151J 60V 71.0~84.0V 6000A 150J 74.0V

Part Number Working Voltage Breakdown Voltage Clamping Surge Typical Cap.

Symbol VDC VB(1mA) VC(max.) IPEAK(8/20μS) C(1KHz)

SFI1206SC120-501A 9V 12V 30V 500A 3500pF

SFI1206SC240-501A 18V 24V 45V 500A 2300pF

SFI1206SC470-501A 38V 47V 85V 500A 690pF

SFI1206SC560-102A 45V 56V 90V 1000A 800pF

SFI1206SC750-501A 60V 75V 100V 500A 300pF

Part Number Working Voltage Breakdown Voltage Clamping Surge Typical Cap.

Symbol VDC VB(1mA) VC(max.) IPEAK(8/20μS) C(1KHz)

SFI1210SC101-401A 85V 100V 165V 400A 250pF

SFI1210SC240-102A 18V 24V 45V 1000A 2300pF

SFI1210SC470-102A 38V 47V 85V 1000A 1550pF

SFI1210SC750-102A 60V 75V 100V 1000A 930pF

SFI1210SC750-182A 60V 75V 100V 1800A 980pF

Part Number Working Voltage Breakdown Voltage Clamping Surge Typical Cap.

Symbol VDC VB(1mA) VC(max.) IPEAK(8/20μS) C(1KHz)

SFI1812SC240-202A 18V 24V 45V 2000A 4500pF

SFI1812SC470-202A 38V 47V 85V 2000A 2100pF

SFI1812SC750-202A 60V 75V 100V 2000A 1650pF

Part Number Working Voltage Breakdown Voltage Clamping Surge Typical Cap.

Symbol VDC VB(1mA) VC(max.) IPEAK(8/20μS) C(1KHz)

SFI2220SC240-103A 16V 24V 45V 10000A 18000pF

SFI2220SC240-302A 18V 24V 45V 3000A 5500pF

SFI2220SC470-502A 38V 47V 85V 5000A 9900pF

SFI2220SC470-802A 38V 47V 85V 8000A 7500pF

SFI2220SC680-802A 56V 68V 100V 8000A 5600pF

SFI2220SC720-402A 58V 72V 100V 4000A 4000pF

SFI2220SC750-302A 60V 75V 100V 3000A 2000pF

SFI2220SC820-602A 65V 82V 135V 6000A 3500pF

Part Number Working Voltage Breakdown Voltage Clamping Surge Typical Cap.

Symbol VDC VB(1mA) VC(max.) IPEAK(8/20μS) C(1KHz)

SFI3220SC240-203A 18V 24V 45V 20000A 22000pF

Part Number Working Voltage Breakdown Voltage Clamping Surge Typical Cap.

Symbol VDC VB(1mA) VC(max.) IPEAK(8/20μS) C(1KHz)

SFI4032SC770-183A 63V 71~84V 120V 18000A 12500pF

SFI4032SC770-253A 63V 71~84V 120V 25000A 12500pF

Part Number Working Voltage Breakdown Voltage Clamping Surge Voltage Surge Current

Symbol VDC VB(1mA) VC(max.) VSurge(10/700μs) IPeak(10/700μs)

SFI0806SN750-010K 60V 75V 100V 1KV 300A

Part Number Working Voltage Breakdown Voltage Clamping Surge Voltage Surge Current

Symbol VDC VB(1mA) VC(max.) VSurge(10/700μs) IPeak(10/700μs)

SFI1206SN120-040K 9V 12V 30V 4KV 100A

SFI1206SN120-060K 9V 12V 30V 6KV 150A

Part Number Working Voltage Breakdown Voltage Clamping Surge Voltage Surge Current

Symbol VDC VB(1mA) VC(max.) VSurge(10/700μs) IPeak(10/700μs)

SFI1210SN470-040K 38V 47V 75V 4KV 100A

SFI1210SN470-060K 38V 47V 75V 6KV 150A

SFI1210SN750-040K 60V 75V 100V 4KV 100A

SFI1210SN750-060K 60V 75V 100V 6KV 150A

SFI1210SN750-080K 60V 75V 105V 8KV 200A

SFI1210SN820-060S 60V 67.5V 100V 6KV 150A

Part Number Working Voltage Breakdown Voltage Clamping Surge Voltage Surge Current

Symbol VDC VB(1mA) VC(max.) VSurge(10/700μs) IPeak(10/700μs)

SFI1812SN471-030K 385V 470V 775V 3KV 75A

Part Number Working Voltage Working Voltage Breakdown Voltage Clamping Surge

Symbol VAC VDC VB(1mA) VC(max.) IPeak(8/20μs)

SFI0806SV241-201A 150V 200V 240V 395V 200A

SFI0806SV271-201A 175V 255V 270V 450V 200A

SFI0806SV431-101A 275V 350V 430V 705V 100A

Part Number Working Voltage Working Voltage Breakdown Voltage Clamping Surge

Symbol VAC VDC VB(1mA) VC(max.) IPeak(8/20μs)

SFI1206SV241-351A 150V 200V 240V 395V 350A

SFI1206SV391-101A 250V 320V 390V 647V 100A

SFI1206SV431-201A 275V 350V 430V 705V 200A

SFI1206SV471-101A 300V 385V 470V 775V 100A

SFI1206SV471-201A 300V 385V 470V 775V 200A

SFI1206SV511-101A 315V 410V 510V 845V 100A

Part Number Working Voltage Working Voltage Breakdown Voltage Clamping Surge

Symbol VAC VDC VB(1mA) VC(max.) IPeak(8/20μs)

SFI1210SV241-201A 193V 195V 240V 395V 200A

SFI1210SV271-801A 175V 225V 270V 450V 800A

SFI1210SV391-201A 250V 320V 390V 647V 200A

SFI1210SV431-501A 275V 350V 430V 705V 500A

SFI1210SV471-251A 300V 385V 470V 775V 250A

SFI1210SV471-501A 300V 385V 470V 775V 500A

SFI1210SV511-351A 315V 410V 510V 845V 350A

Part Number Working Voltage Working Voltage Breakdown Voltage Clamping Surge

Symbol VAC VDC VB(1mA) VC(max.) IPeak(8/20μs)

SFI1812SV271-102A 175V 225V 270V 450V 1000A

SFI1812SV271-202A 175V 225V 270V 450V 2000A

SFI1812SV271-501A 175V 225V 270V 450V 500A

SFI1812SV431-801A 275V 350V 430V 705V 800A

SFI1812SV471-102A 300V 385V 470V 775V 1000A

SFI1812SV471-501A 300V 385V 470V 775V 500A

SFI1812SV471-801A 300V 385V 470V 775V 800A

Part Number Working Voltage Working Voltage Breakdown Voltage Clamping Surge

Symbol VAC VDC VB(1mA) VC(max.) IPeak(8/20μs)

SFI2220SV241-801A 139V 195V 240V 395V 800A

SFI2220SV271-501A 175V 225V 270V 450V 500A

SFI2220SV271-801A 175V 225V 270V 450V 800A

SFI2220SV391-501A 250V 320V 390V 647V 500A

SFI2220SV391-801A 250V 320V 390V 647V 800A

SFI2220SV431-501A 275V 350V 430V 705V 500A

SFI2220SV431-801A 275V 350V 430V 705V 800A

SFI2220SV471-182A 300V 385V 470V 775V 1800A

SFI2220SV471-202A 300V 385V 470V 775V 2000A

SFI2220SV471-501A 300V 385V 470V 775V 500A

SFI2220SV471-801A 300V 385V 470V 775V 800A

SFI2220SV681-801A 420V 560V 680V 1120V 800A

Part Number Working Voltage Working Voltage Breakdown Voltage Clamping Surge

Symbol VAC VDC VB(1mA) VC(max.) IPeak(8/20μs)

SFI3220SV271-501A 175V 225V 270V 450V 500A

SFI3220SV271-801A 175V 225V 270V 450V 1000A

SFI3220SV431-801A 275V 350V 430V 705V 1000A

SFI3220SV471-302A 300V 385V 470V 775V 3000A

SFI3220SV471-801A 300V 385V 470V 775V 1000A

SFI3220SV511-252A 315V 410V 510V 845V 2500A

SFI3220SV681-102A 420V 560V 680V 1120V 1000A

SFI3220SV821-102A 500V 650V 820V 1350V 1000A

Part Number Reverse Working Voltage Parasitic Capacitance Clamping Voltage(ESD and TLP) Peak Pulse Power Peak Pulse Current

Symbol VRWM(max.) CESD(1MHz)(typ.) VCL(VESD 8KV) PPK(8/20μs) IPP(8/20μs)

SFI0402TA3R3-100K 3.3V 10pF 10V 80W 8A

SFI0402TA050-0R3W 5.0V 0.3pF 30V 54W 3A

SFI0402TA050-2R5A 5V 2.5pF 16V 45W 3A

SFI0402TA050-100A 5.0V 10pF 12V 96W 8A

SFI0402TA050-170K 5.0V 17pF 12V 80W 8A

SFI0402TA070-100A 7.0V 12pF 12V 72W 6A

SFI0402TA120-060A 12.0V 6pF 18V 120W 6A

SFI0603TA3R3-100K 3.3V 10pF 10V 80W 8A

SFI0603TA050-2R5A 5.0V 2.5pF 16V 45W 3A

SFI0603TA050-100A 5.0V 10pF 12V 96W 8A

Part Number Reverse Working Voltage Parasitic Capacitance Clamping Voltage

(ESD and TLP) Peak Pulse Power Peak Pulse Current

Symbol VRWM(max.) CESD(1MHz)(typ.) VCL(VESD 8KV) PPK(8/20μs) IPP(8/20μs)

SFI0402TD3R3-0R5A 3.3V 0.35pF 11V 60W 3A

SFI0402TD240-0R5A 24.0V 0.35pF 15V 24W 3A

Part Number Reverse Working Voltage Parasitic Capacitance Clamping Voltage(ESD and TLP) Peak Pulse Power Peak Pulse Current

Symbol VRWM(max.) CESD(1MHz)(typ.) VCL(VESD 8KV) PPK(8/20μs) IPP(8/20μs)

SFI0402TN050-1R5A 5.0V 1.5pF 12V 300W 15A

SFI0402TN050-0R8A 5.0V 0.8pF 13V 100W 7A

Part Number Reverse Working Voltage Parasitic Capacitance Clamping Voltage(ESD and TLP) Peak Pulse Power Peak Pulse Current

Symbol VRWM(max.) CESD(1MHz)(typ.) VCL(VESD 8KV) PPK(8/20μs) IPP(8/20μs)

SFI0201TS3R3-100W 3.3V 10pF 12V 70W 7A

SFI0201TS050-100W 5.0V 10pF 12V 72W 6A

SFI0201TS050-0R3A 5V 0.3pF 30V 60W 3A

SFI0201TS050-2R5A 5.0V 2.5pF 16V 45W 3A

SFI0402TS3R3-100K 3.3V 10pF 10V 80W 8A

SFI0402TS050-0R3W 5.0V 0.3pF 30V 54W 3A

SFI0402TS050-0R5A 5.0V 0.35pF 15V 60W 4A

SFI0402TS050-2R5A 5.0V 2.5pF 16V 45W 3A

SFI0402TS050-050A 5.0V 5pF 16V 45W 3A

SFI0402TS050-100A 5.0V 10pF 12V 96W 8A

SFI0402TS050-170K 5.0V 17pF 12V 80W 8A

SFI0402TS050-300A 6.5V 0.3pF 30V 54W 3A

SFI0402TS070-100A 7.0V 12pF 13V 72W 6A

SFI0402TS120-060A 12.0V 6pF 18V 120W 6A

SFI0603TS050-R3W 5.0V 0.3pF 30V 54W 3A

SFI0603TS050-100A 5.0V 10pF 12V 96W 8A

SFI0603TS050-2R5A 5.0V 2.5pF 16V 45W 3A

SFI0603TS3R3-100K 3.3V 10pF 10V 80W 8A

一级代理SFI一级代理SFI代理立昌一级代理立昌一级代理立昌代理

其它

SFI0402EH060-0R20P 300 30 0.2 402

SFI0402EH240-0R20P 300 30 0.2 402

SFI0603EH060-0R20P 300 30 0.2 603

SFI0603EH240-0R20P 300 30 0.2 603

SFI0201-120E0R8PP-LF 100-150 200 0.8 201

SFI0201-120E2R5PP-LF 60~80 130 2.5 201

SFI0201-050E050PP-LF 28~38 72 5 201

SFI0201-050E100NP-LF 28~38 72 10 201

SFI0201-050E330NP-LF 18~28 48 33 201

SFI0402-240E0R8PP-LF 100-150 200 0.8 402

SFI0402-240E2R5PP-LF 100-150 200 2.5 402

SFI0402-240E3R0PP-LF 48~72 200 3 402

SFI0402-050E050PP-LF 28~38 72 5 402

SFI0402-050E100NP-LF 28~38 72 10 402

SFI0402-050E220NP-LF 18~28 52 22 402

SFI0402-050E330NP-LF 18~28 52 33 402

SFI0402-050E560NP-LF 18~28 52 56 402

SFI0402-050E101NP-LF 18~28 52 100 402

SFI0402-120E101NP-LF 20~30 55 100 402

SFI0402-120E820NP-LF 20~30 55 82 402

SFI0402-120E560NP-LF 20~30 55 56 402

SFI0402-120E330NP-LF 20~30 55 33 402

SFI0402-120E220NP-LF 20~30 55 22 402

SFI0402-120E100NP-LF 28~38 72 10 402

SFI0402-120E050PP-LF 28~38 72 5 402

SFI0402-420E0R8PP-LF 100-150 200 0.8 402

SFI0603-240E0R8PP-LF 100-150 200 0.8 603

SFI0603-240E2R5PP-LF 100-150 240 2.5 603

SFI0603-050E050PP-LF 20~30 55 5 603

SFI0603-050E100NP-LF 24~36 55 10 603

SFI0603-050E220NP-LF 15~25 34 22 603

SFI0603-050E330NP-LF 15~25 34 33 603

SFI0603-050E560NP-LF 15~25 36 56 603

SFI0603-050E101NP-LF 15~25 36 100 603

SFI0603-120E101NP-LF 20~30 55 100 603

SFI0603-120E560NP-LF 20~30 55 56 603

SFI0603-120E330NP-LF 20~30 55 33 603

SFI0603-120E220NP-LF 20~30 55 22 603

SFI0603-120E100NP-LF 27~42 60 10 603

SFI0603-120E050NP-LF 33~50 85 5 603

SFI0402ML080C-LF 5.5 50 8 20 20 160 10000

SFI0402ML120C-LF 9 50 12 20 20 110 10000

SFI0402ML150C-LF 11 50 15 25 20 75 10000

SFI0402ML180C-LF 14 50 18 35 20 50 10000

SFI0402ML240C-LF 18 50 24 40 15 45 10000

SFI0402ML270C-LF 22 50 27 45 20 75 10000

SFI0402ML330C-LF 26 50 33 54 20 54 10000

SFI0402ML330C-LF 30 50 39 65 20 45 10000

SFI0603ML080C-LF 5.5 30 8 20 30 360 4000

SFI0603ML120C-LF 9 50 12 20 30 300 4000

SFI0603ML150C-LF 11 50 15 25 30 250 4000

SFI0603ML180C-LF 14 50 18 30 30 210 4000

SFI0603ML240C-LF 18 50 24 39 30 160 4000

SFI0603ML270C-LF 22 50 27 39 30 145 4000

SFI0603ML330C-LF 26 50 33 54 30 130 4000

SFI0603ML390C-LF 30 50 39 65 30 110 4000

SFI0603ML470C-LF 38 50 47 77 30 90 4000

SFI0805ML080C-LF 5.5 50 8 20 80 1400 3000

SFI0805ML120C-LF 9 50 12 20 80 650 3000

SFI0805ML150C-LF 11 50 15 25 100 410 3000

SFI0805ML180C-LF 14 50 18 30 100 350 3000

SFI0805ML240C-LF 18 50 24 39 100 300 3000

SFI0805ML330C-LF 27 50 33 54 100 220 3000

SFI0805ML390C-LF 30 50 39 65 100 200 3000

SFI0805ML470C-LF 38 50 47 77 100 150 3000

SFI0805ML560C-LF 45 50 56 90 80 110 3000

SFI1206ML080C-LF 5.5 50 8 20 100 3100 3000

SFI1206ML180A-LF 14 50 18 30 200 1200 3000

SFI1206ML240A-LF 18 50 24 39 200 780 3000

SFI1206ML270C-LF 22 50 27 44 100 700 3000

SFI1206ML330C-LF 26 50 33 54 100 480 3000

SFI1206ML390A-LF 30 50 39 65 200 510 3000

SFI1206ML470A-LF 38 50 47 77 200 440 3000

SFI1206ML560C-LF 45 50 56 90 100 230 3000

SFI1206ML680C-LF 56 50 68 110 100 200 3000

SFI1206ML820C-LF 65 50 82 135 100 175 3000

SFI1206ML101C-LF 85 50 100 165 100 150 3000

SFI1210ML080C-LF 5.5 50 8 20 250 5200 2000

SFI1210ML120C-LF 9 50 12 20 250 4400 2000

SFI1210ML150A-LF 11 50 15 25 400 4050 2000

SFI1210ML180A-LF 14 50 18 30 400 3860 2000

SFI1210ML240A-LF 18 50 24 39 400 2380 2000

SFI1210ML270A-LF 22 50 27 44 400 2100 2000

SFI1210ML330A-LF 26 50 33 54 400 1400 2000

SFI1210ML390A-LF 30 50 39 65 400 1180 2000

SFI1210ML470A-LF 38 50 47 77 400 1000 2000

SFI1210ML560A-LF 45 50 56 90 400 660 2000

SFI1210ML680C-LF 56 50 68 110 250 390 2000

SFI1210ML820C-LF 65 50 82 135 250 320 2000

SFI1210ML101C-LF 85 50 100 165 200 220 2000

SFI1210ML121C-LF 100 50 120 200 200 180 2000

SFI1812ML180A-LF 14 50 18 30 500 3500 1000

SFI1812ML240A-LF 18 50 24 38 800 3500 1000

SFI1812ML390A-LF 30 50 39 65 800 2350 1000

SFI1812ML470A-LF 38 50 47 77 800 1600 1000

SFI1812ML560A-LF 45 50 56 90 800 1200 1000

SFI1812ML560A-LF 56 50 68 110 500 700 1000

SFI1812ML151C-LF 127 50 150 270 600 330 1000

SFI2220ML180A-LF 14 50 18 30 1200 10500 1000

SFI2220ML240A-LF 18 50 24 39 1200 8500 1000

SFI2220ML270A-LF 22 50 27 44 1200 8300 1000

SFI2220ML330C-LF 26 50 33 54 1200 3900 1000

SFI2220ML470A-LF 38 50 47 77 1200 4000 1000

SFI2220ML560A-LF 45 50 56 90 1200 3500 1000

SFI0806SV241-201A 200 50 240 395 200 95 2000

SFI1206SV241-351A 200 50 240 395 350 180 2000

SFI0806SV431-101A 350 50 430 705 100 95 2000

SFI1206SV431-201A 350 50 430 705 200 60 2000

SFI1206SV471-101A 385 50 470 775 100 30 2000

SFI1210SV271-801A 225 50 270 450 800 350 1500

SFI1210SV391-201A 320 50 390 647 200 105 1500

SFI1210SV471-501A 385 50 470 775 500 190 1500

SFI1812SV271-102A 225 50 270 450 1000 600 500

SFI1812SV471-501A 385 50 470 775 500 200 500

SFI1812SV471-801A 385 50 470 775 800 310 500

SFI2220SV271-801A 225 50 270 450 800 350 500

SFI2220SV391-801A 320 50 390 647 800 320 500

SFI2220SV431-801A 350 50 430 705 800 305 500

SFI2220SV471-801A 385 50 470 775 800 290 500

SFI2220SV471-501A 385 50 470 775 500 195 500

SFI2220SV471-182A 385 50 470 775 1800 600 500

SFI2220SV681-182A 560 50 680 1120 1800 210 500

SFI3220SV271-501A 225 50 270 450 500 340 500

SFI3220SV271-801A 225 50 270 450 800 550 500

SFI3220SV271-302A 225 50 270 450 3000 500

SFI3220SV391-302A 320 50 390 647 3000 900 500

SFI3220SV431-801A 350 50 430 705 800 490 500

SFI3220SV471-801A 385 50 470 775 800 450 500

SFI3220SV681-102A 560 50 680 1120 1800 1300 500

SFI3220SV511-252A 410 50 510 845 2500 600 500

SFI1206SN120-040K 9 10 12 30 100 10 700 3200 2000

SFI1206SN120-060K 9 10 12 30 150 10 700 3850 2000

SFI1210SN470-060K 38 10 47 75 150 10 700 1670 1500

SFI1210SN750-040K 60 50 75 100 100 10 700 1000 1500

SFI1210SN750-060K 60 50 75 100 150 10 700 1300 1500

SFI1210SN750-080K 60 50 75 105 200 10 700 1350 1500

SFI1206SC120-501A 9 10 12 30 500 3500 2000

SFI1206SC240-501A 18 10 24 45 500 2300 2000

SFI1206SC470-501A 38 10 47 85 500 690 2000

SFI1206SC560-102A 45 10 56 90 1000 800 2000

SFI1206SC750-501A 60 10 75 100 1000 300 2000

SFI1210SC101-401A 85 10 100 165 400 250 1500

SFI1210SC240-102A 18 15 24 45 1000 2300 1500

SFI1210SC470-102A 38 10 47 85 1000 1550 1500

SFI1210SC750-102A 60 50 75 100 1000 930 1500

SFI1812SC240-202A 18 15 24 45 2000 4500 500

SFI1812SC470-202A 38 15 47 85 2000 2100 500

SFI1812SC750-202A 60 15 75 100 2000 1650 500

SFI2220SC240-103A 18 50 24 45 10000 18000 500

SFI2220SC240-302A 18 50 24 45 3000 5500 500

SFI2220SC470-502A 38 15 47 85 5000 9900 500

SFI2220SC470-802A 38 15 47 85 8000 7500 500

SFI2220SC680-802A 56 50 68 100 8000 5600 500

SFI2220SC750-302A 60 15 75 100 3000 2000 500

SFI2220SC820-602A 65 15 82 135 6000 3500 500

SFI3220SC240-203A 18 50 24 45 20000 22000 500

SFI0805SA240-1R5J 16 5 24 40 200 1.5 24.5 720 2000

SFI0806SA360-360V 24 50 36 55 300 9 35 550 2000

SFI01206SA240-030J 16 5 24 40 400 3 24.5 1800 2000

SFI01206SA240-060J 16 5 24 40 500 6 24.5 2100 2000

SFI01206SA360-090J 16 5 36 55 500 9 35 830 2000

SFI0402TS050-050A-11 5 0.2 5.2 12 16 4 64 5 402

SFI0402TS050-0R3W-11 5 0.1 7 12 18 3 54 0.3 402

SFI0402TS050-100A-11 5 0.08 5.5 8 12 8 96 10 402

SFI0402TS050-170K-11 5 1 5.1 6.5 10 10 80 17 402

SFI0402TS050-2R5A-11 5 0.1 5.5 12 15 3 45 2.5

价格说明

商品规格	交付清单	数量/时长	含税价格
SFI立昌SFI0402-120E100NP-LF	TVS 10000个	1个	￥111

售后服务

发票信息

支持开具增值税专用发票(可抵扣)

服务保障

质保期： 1年

保障说明：欢迎研件研发前来交流并提供原厂技术支持！

文档下载

SFI产品介绍Over Voltage Portection Solution_2015.pdf

SFI立昌一级代理经销KOYUELEC光与电子.pdf

深圳市光与电子有限公司

百度AI市场

SFI立昌SFI0402-120E100NP-LF

SFI立昌一级代理分销KOYUELEC光与电子SFI0402-120E100NP-LF
